SMAG – Screen Printing Equipment
Multi-process ICON platform ICONCEPT for value-added printing, finishing and converting
The ICONCEPT is the most advanced product line from the ICON multi-process platform, incorporating a wide choice of printing and converting modules fully servo-driven, independent in terms of repeat length, automatic registration systems and web motion.
It is infinitely adaptable, for solutions tailored to every market application. The platform is also modular and mature, with worldwide references from leading label printers.
Finishing and converting processes
- Compact or extended unwinders diameters (850 / 1000 / 1200) mm.
- Pre-equipment on unwinder to receive corona treatment and web cleaner.
- Die cutting unit in servo-rotary and semi-rotary versions, or DGV-type flatbed.
- Waste matrix with pressure arm and Snowball system.
- Visualization, 100% inspection and control module with a wide range of cameras available.
- Wide choice of slitting units with interchangeable cassette for shear knives, razors blades, pressure knives, underscoring, or shear knives with automatic positioning.
- Single and dual shaft rewinders for simultaneous or alternating rewinding of finished products.
- Semi-automatic rewinder with 2-shafts.
- Non-stop 2-shafts rewinder with automatic gluing system.
- Roll to sheet output with conveyor.
Printing processes and added value
- Flexo units available in mechanical rotary, rotary servo or semi-rotary servo versions with UV / LED / hot air / IR drying systems.
- Delam / relam for flexo printing on adhesive side.
- Laminating and cold foil stamping.
- Inkjet printing for variable data.
- SP flatbed screen printing with UV / LED / hot air / IR air / IR.
- Silk-foil printing process (heat lamination of foil after screen printing).
- HGV flatbed foil and embossing with foil saver.
- Optional rotating head on the flat bed hot stamping HGV module for transversal foil.
- Flat embossing type EGV.
- Semi-rotary hot foil stamping with foil saver.
- Applications modules for coupon labels, booklets and labels dispensing.
- Parts removing system.
CLASSIC GALAXIE: Roll-to-roll flatbed screen printing press
Flatbed screen printing process and GALAXIE CLASSIC
The Galaxie Classic reel-to-reel screen printing press was launched on the market in 1995 at the Label’Expo Europe trade show. To date, over 800 machines of this type have been installed on all five continents.
The first generations of Galaxie are still in production with our customers. This tried-and- tested mature machine is recognized as the benchmark for high-value labels in the luxury, perfume, spirits and industrial sectors, where print quality and durability are essential.
CLASSIC
GALAXIE
Advantages of screen printing over other printing techniques
- High ink resistance: mechanical (friction), chemical and light.
- Extremely high opacity,
- Very high ink deposit,
- Sensory and tactile effects,
- Special ink applications such as thermocromic and conductive inks…
Modules available on Galaxie Classic
- Screen printing with UV, Infrared and hot-air dryers,
- Semi-rotary flexographic printing,
- Inkjet printing,
- And all in-line finishing modules: foiling, embossing, laminating, die- cutting, waste rewinding, slitting, rewinding….
Advantages of the Galaxie Classic
- Extremely high register tolerance in single and multi-pass operation,
- Low waste during makeready and printing,
- Total modularity, possibility of constant upgrading,
- A wide range of widths and formats,
- User-friendly.
